Industrial Workbench Model A-107P
- Adjustable-Height -

Click Here for More Information & to Request a Quote...

• Ergonomic Lift Table Height Adjustability (Options)
  • Hydraulic-Assisted Height Adjustment w/ Electric Motor or Hand Crank
    • Switch for Electric Motor Unit can be positioned anywhere on the unit...
    • Hand Crank is mounted below work surface (Front or Side)
  • Manually-Adjusted Height Option w/ Leg Pins
• Standard Sizes:
  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...
  • "A" - 48", 60" & 72" Width (Right-to-Left)
    • Minimum Top/Unit Widths (Required to Accommodate Hydraulic System):
      • Electric Motor Hydraulic System:
        • 6" Lift - 28" Min. Width
        • 8" Lift - 30" Min. Width
        • 10" Lift - 32" Min. Width
        • 12" Lift - 34" Min. Width
        • 14" Lift - 36" Min. Width
        • 16" Lift - 38" Min. Width
      • Manual Crank Hydraulic System (Min Depth if Hand Crank located at front of Unit):
        • 6" Lift - 15" Min. Width or Depth
        • 8" Lift - 17" Min. Width or Depth
        • 10" Lift - 20" Min. Width or Depth
        • 12" Lift - 22" Min. Width or Depth
        • 14" Lift - 24" Min. Width or Depth
        • 16" Lift - 26" Min. Width or Depth
  • "B" - 30" & 36" Depth (Front-to-Back)
  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)
• 1,000 pound capacity - 4 Leg Unit (Less Weight of Unit)
• 1,500 pound capacity available - 4 & 6 Leg Unit (Less Weight of Unit)
• 3,000 pound capacity - 4 Leg Unit (Less Weight of Unit) - Available 12" Lift Only w/ Motor
• 20,000 pound capacity - 4 Leg Unit (Less Weight of Unit) - Available 12" Lift Only w/ Motor
• Fully-Welded Tubular Steel Frame
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.
• Many Top Options to Choose From, Including Plastic Laminate, Chemical Resistant, ESD /
  Static-Control, Solid Surface, Solid Wood (Butcher Block), Stainless Steel, and More...

 NOTE:  Adjustable-Height Option (Including Hydraulic Lift Systems) can be applied to all workbench models shown below...

Industrial Workbench Model A-109P
- Standard Flat-Top Table -

Click Here for More Information & to Request a Quote...

• Durable Steel Frame Construction w/ Lower Crossmember (Can be used as a footrest)
• Standard Sizes:
  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...
  • "A" - 48", 60" & 72" Width (Right-to-Left)
  • "B" - 30" & 36" Depth (Front-to-Back)
  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)
• Fully-Welded Tubular Steel Frame Connections
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.
• Many Top Options to Choose From, Including Plastic Laminate, Chemical Resistant, ESD /
  Static-Control, Solid Surface, Solid Wood (Butcher Block), Stainless Steel, and More...

Industrial Workbench Model A-109PCLG
Adds Center Legs (6 legs total) for...
- Heavy Duty Weight Capacity (over 1,000 pounds)
OR... Extra-Long Tables (9'-0" & Greater) -

Click Here for More Information & to Request a Quote...

• For oversized items or loads greater than 1000 pounds...
• Durable Steel Frame Construction w/ Lower Crossmember (Can be used as a footrest)
• Standard Sizes:
  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...
  • "A" - 48", 60" & 72" Width (Right-to-Left)
  • "B" - 30" & 36" Depth (Front-to-Back)
  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)
• Fully-Welded Tubular Steel Frame Connections
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.
• Many Top Options to Choose From, Including Plastic Laminate, Chemical Resistant, ESD /
  Static-Control, Solid Surface, Solid Wood (Butcher Block), Stainless Steel, and More...

Industrial Workbench Model A-109PE
- Economy (Light-Duty) Flat-Top Table -

Click Here for More Information & to Request a Quote...

• Durable Steel Frame Construction - Light Duty Usage - No Lower Crossmember
• Standard Sizes:
  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...
  • "A" - 48", 60" & 72" Width (Right-to-Left)
  • "B" - 30" & 36" Depth (Front-to-Back)
  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)
• Fully-Welded Tubular Steel Frame Connections
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.
• Many Top Options to Choose From, Including Plastic Laminate, Chemical Resistant, ESD /
  Static-Control, Solid Surface, Solid Wood (Butcher Block), Stainless Steel, and More...

Industrial Workbench Model C-103P
- Unobstructed Leg Movement w/ Upper Shelf -
(Recessed Front Legs ...)

Click Here for More Information & to Request a Quote...

• Recessed Front Legs

• Durable Steel Frame Construction w/ Lower Crossmember (Can be used as a footrest)

• Overhead Shelf for Added Surface Space / Storage

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width (Right-to-Left)

  • "B" - 30" & 36" Depth (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 12" to 18"

  • "E" - 18" to 24" (Add 3 1/2" to your under-shelf clearance requirement)

• Fully-Welded Tubular Steel Frame Connections

• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...

• Durable Tubular Steel Table Legs w/ Leveler Feet.

  NOTE:  C-Frame configuration can be applied to most of our workbench models...

Industrial Workbench Model C-109P
- Flat Table w/ Unobstructed Leg Movement -
(Front Legs Recessed...)

Click Here for More Information & to Request a Quote...

• Standard Sizes:
  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...
  • "A" - 48", 60" & 72" Width (Right-to-Left)
  • "B" - 30" & 36" Depth (Front-to-Back)
  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)
• Fully-Welded Tubular Steel Frame Connections
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.
• Optional Tilting Top Work Surface

  NOTE:  C-Frame configuration can be applied to most of our workbench models...

Industrial Workbench Model ER-108P
- Equipment Rack Workstation -

Click Here for More Information & to Request a Quote...

• Open Frame Architecture Equipment Rack - Accommodates industry standard EIA 19" wide equipment.  24" wide EIA industry standard also available...

• Durable Steel Frame Construction w/ Lower Crossmember (Can be used as a footrest)

• Adjustable-Height Overhead Flow Rack Shelf or Shelves (Specify Quantity Desired)

• Adjustable (Front-to-Back) Fluorescent Lamp Fixture Boom

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width (Right-to-Left)

  • "B" - 30" & 36" Overall Unit Depth (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 25", 30", or 36" (Front-to-Back Depth of Equipment Rack Bays)

  • "E" - Height of Rack Bays (30" typ. - Up to 70")

  • "F" - Height of Upper Cabinet (14"typ.)

• Fully-Welded Tubular Steel Frame Connections (Base)
• Durable Tubular Steel Table Legs w/ Leveler Feet.

Industrial Workbench Model F-103P
- Table w/ Standard Upper Shelf... -

Click Here for More Information & to Request a Quote...

• Durable Steel Frame Construction w/ Lower Crossmember (Can be used as a footrest)

• Overhead Shelf for Added Surface Space / Storage

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width (Right-to-Left)

  • "B" - 30" & 36" Depth (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 12" to 18"

  • "E" - 18" to 24" (Add 3 1/2" to your under-shelf clearance requirement)

• Fully-Welded Tubular Steel Frame Connections

• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...

• Durable Tubular Steel Table Legs w/ Leveler Feet.

Industrial Workbench Model F-103PCLG
Adds Center Legs (6 legs total) for...
- Heavy Duty Weight Capacity (over 1,000 pounds)
OR... Extra-Long Tables (9'-0" & Greater) -

Click Here for More Information & to Request a Quote...

• For oversized items or loads greater than 1000 pounds...

• Durable Steel Frame Construction w/ Lower Crossmember (Can be used as a footrest)

• Overhead Shelf for Added Surface Space / Storage

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width (Right-to-Left)

  • "B" - 30" & 36" Depth (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 12" to 18"

  • "E" - 18" to 24" (Add 3 1/2" to your under-shelf clearance requirement)

• Fully-Welded Tubular Steel Frame Connections

• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...

• Durable Tubular Steel Table Legs w/ Leveler Feet.

• Many Top Options to Choose From, Including Plastic Laminate, Chemical Resistant, ESD /
  Static-Control, Solid Surface, Solid Wood (Butcher Block), Stainless Steel, and More...

Industrial Workbench Model F-103PE
- Economy (Light-Duty) Table w/ Upper Shelf -

Click Here for More Information & to Request a Quote...

• Durable Steel Frame Construction - Light Duty Usage - No Lower Crossmember

• Overhead Shelf for Added Surface Space / Storage

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width (Right-to-Left)

  • "B" - 30" & 36" Depth (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 12" to 18"

  • "E" - 18" to 24" (Add 3 1/2" to your under-shelf clearance requirement)

• Fully-Welded Tubular Steel Frame Connections
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.

Industrial Workbench Model F-103PL/DS
- Table w/ Multiple Upper Shelves -

Click Here for More Information & to Request a Quote...

• Durable Steel Frame Construction w/ Lower Crossmember (Can be used as a footrest)

• Dual Overhead Shelves for Added Surface Space / Storage

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width (Right-to-Left)

  • "B" - 30" & 36" Depth (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 12" to 18"

  • "E" - 18" to 24" (Add 3 1/2" to your under-shelf clearance requirement)

  • "F" - 12" to 18" (Note:  Keep Overall Height of Bench Below 7'-0" for Ease of Use...)

• Fully-Welded Tubular Steel Frame Connections
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.

Industrial Workbench Model F-107P
- Adjustable -
Our Most Versatile Table System...

Click Here for More Information & to Request a Quote...

• Durable Steel Frame Construction w/ Lower Crossmember (Can be used as a footrest)

• Adjustable-Height Main Work Surface

• Adjustable-Height Overhead Shelf for Added Surface Space / Storage

• Adjustable Flourescent Light Boom (Front-to-Back)

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width (Right-to-Left)

  • "B" - 30" & 36" Depth (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 12" to 18"

  • "E" - 18" to 24" (Add 3 1/2" to your under-shelf clearance requirement)

  • "F" - Typically Same as "B"

• Fully-Welded Tubular Steel Frame Connections (Base)
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.
• Channeled rear legs accept many workbench accessories...

Industrial Workbench Model T-101P -
Double-Sided Table System -
w/ Cantilevered Work Surface(s)...

Click Here for More Information & to Request a Quote...

• Durable Steel Frame Construction

• Adjustable-Height Overhead Shelf for Added Surface Space / Storage

• Adjustable (Front-to-Back) Fluorescent Lamp Fixture Boom

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width of Main Work Surface (Right-to-Left)

  • "B" - 30" & 36" Depth of Main Work Surface (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 12" to 18" Shelf Depth (Front-to-Back)

  • "E" - 18" to 24" Shelf Height (Add 3 1/2" to your under-shelf clearance requirement)

  • "F" - Typically Same as "B" (Depth of Overhead Lamp)

• Fully-Welded Tubular Steel Frame Connections (Base)
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.
• Channeled rear legs accept many workbench accessories...

Industrial Workbench Model P-107P
- Packing /Shipping WorkStation -

Click Here for More Information & to Request a Quote...

• Durable Steel Frame Construction w/ Lower Crossmember (Can be used as a footrest)

• Adjustable-Height Overhead Shelf for Added Surface Space / Storage

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width (Right-to-Left)

  • "B" - 30" & 36" Depth (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 12" to 18" (Depth of 1st Upper Shelf)

  • "E" - 18" to 24" (Add 3 1/2" to your under-shelf clearance requirement)

• Fully-Welded Tubular Steel Frame Connections (Base)
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.
• Channeled rear legs accept many workbench accessories...

Industrial Workbench Model FR-104P
- Table w/ Flow Rack Shelving -

Click Here for More Information & to Request a Quote...

• Durable Steel Frame Construction w/ Lower Crossmember (Can be used as a footrest)

• Adjustable-Height Overhead Flow Rack Shelf or Shelves (Specify Quantity Desired)

• Adjustable (Front-to-Back) Fluorescent Lamp Fixture Boom

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width (Right-to-Left)

  • "B" - 30" & 36" Depth (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 12" to 18" (Front-to-Back Depth of Upper Shelf or Shelves)

  • "E" - Height of 1st Upper Shelf (12" typ.)

  • "F" - Height of 2nd and more Upper Shelves (Vertical space between each shelf - 6"typ.)

• Fully-Welded Tubular Steel Frame Connections (Base)
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• Durable Tubular Steel Table Legs w/ Leveler Feet.
• Channeled rear legs accept many workbench accessories...

Removable Industrial Workbench Riser
 - Removable Upper Shelf for Standard Flat-Top Table -

Click Here for More Information & to Request a Quote...

• Add to any A-Frame Bench
• Bolts to top of Your Existing or New A-Frame Bench
• 250-400 pound capacity (Varies w/ Size)
• Fully-Welded Tubular Steel Frame Connections
• See our Cleanroom Workbench Section for Electropolished Stainless Steel Tables...
• We are the manufacturer - Feel free to specify your custom dimension requirements
  above or choose from the following...

K/D Industrial Workbench
- Knock-Down Table Units (Disassembles) -

Click Here for More Information & to Request a Quote...

• Bolt-Together Frame - Great for Storing, Shipping & Squeezing into tight areas...

• Standard Sizes:

  • We are the manufacturer - Feel free to specify your custom dimension requirements
    above or choose from the following...

  • "A" - 48", 60" & 72" Width (Right-to-Left)

  • "B" - 30" & 36" Depth (Front-to-Back)

  • "C" - 30" (Sitting "Desk" Height), 34" (ADA/Accessible Height), 36" (Standing Tasks)

  • "D" - 12" to 18"

  • "E" - 18" to 24" (Add 3 1/2" to your under-shelf clearance requirement)

• Durable Tubular Steel Table Legs w/ Leveler Feet.
