RDM Industrial ProductsRDM Home Page

RDM Industrial Products

RDM Industrial Products Inc.
M  A  N  U  F  A  C  T  U  R  E  R   -   D  I  S  T  R  I  B  U  T  O  R
Providing Industrial Furniture Solutions for over 30 Years...

McAfee Secure sites help keep you safe from identity theft, credit card fraud, spyware, spam, viruses and online scams

Toll Free
877-777-9130



Standard
Finishes


We Provide Many Finish Options...
Please minimize or close this window to return to
the previous page and input your finish selections...

  Click Here for
Ball

Table Finish
BROCHURE



Paint & Powder Options:
       Metal Cabinet Finish Options...

Metal Frame Color Options
       Laboratory Cabinet / Casework Finish Options...
       Laboratory Fume Hood Finish Options...

Top Finish Options:
  - Plastic Laminates:

       Standard Plastic Laminate Options

Static Dissipative (ESD) Plastic Laminate

Chemical-Resistant Plastic Laminate
  - Solid Surface Top Options:
       Chemical & Heat-Resistant Solid Surface (Epoxy Resin)
       Chemical & Heat-Resistant Solid Surface (Trespa)
  - Wood Top Options:
       Hard Board Masonite

Laminated Hardwood (i.e. Butcher Block)
  - Metal / Steel Top Options:
       Stainless Steel
       Galvanized Steel
       Painted Steel

       Top Edge Options

Other Finish Options:
       Edge Options (Tops)...
        Panolam Melamine Surfaces (Cabinets)
       We also sell Table Mats

We design and fabricate to meet your specifications.
Many surface options are available !!

Metal Frame Finish   RDM Lab Furniture Finishes
Metal Frame
Finishes
  Laboratory
Furniture


Standard Plastic Laminated Top with PVC Edging   Solid Surface Epoxy Resin or Solid Phenolic Top
Standard Top
Laminates
  Solid Surfaces
RDM Edge Options - Extruded Aluminum
Top
Edge Options

Hardwood Maple   Steel Top Finish Options
Wood Tops   Steel Top
Finishes







Metal Frame
Finish Options:


Metal Frame Finish Options:

  Custom Frame

RDM Paint Finish - Dove Grey RDM Paint Finish - Platinum RDM Paint Finish - Light Grey RDM Paint Finish - White
Dove Gray Platinum  Light Grey White
RDM Paint Finish - Designer White RDM Paint Finish - Black Your Choice
(Free 10+Units)
Must send sample
to match...
RDM Paint Finish - Putty (Beige)
Designer White   Black Custom Putty (Beige)
RDM Paint Finish - Industrial Yellow RDM Paint Finish - RDM Blue RDM Paint Finish - RR Blue RDM Paint Finish - Dark Blue
Industrial Yellow RDM Blue RR Blue  Dark Blue
RDM Paint Finish - Green RDM Paint Finish - Traffic Red RDM Paint Finish - Burgundy RDM Paint Finish - Clear Coat
Green  Traffic Red  Burgundy Clear Coat
Note:  Clear coat finish will have a very industrial type of finished look since weld burns, seam lines and some small scratches are extremely labor-intensive to remove.  A clean metal surface with clear coat (i.e. sand blasted) will look very similar to a dark grey paint, but will be much more expensive.





Top Options:


RDM Industrial Products
Plastic-Laminated

Plastic Laminate Surface Color Options:



(Standard Laminates)
White
Formica
949-58
Pionite
SW811-S
Eggshell White
Wilsonart
1572-60
SW803-S
Almond
Wilsonart
D30-60
Pionite
ST655
Beige
Wilsonart
153-60
Pionite
ST617-S
Light Gray
Wilsonart
D381-60
Pionite
SG241-S
Gray
Formica
961-58
Pionite
SG213-S
Blue
Pionite
SB005-S
Black
Wilsonart
1595-60
Pionite
SE101-S
Note:  UPCHARGE applies for Pionite finishes.
Please Note:  These are our typical selections.  We also offer
all current finish and pattern options provided by Formica,
Nevamar, Pionite and Wilsonart.
See Custom Laminate Finish Samples (Formica) RDM Industrial Products (Click Here)
See Custom Laminate Finish Samples (Nevamar) RDM Industrial Products (Click Here)
See Custom Laminate Finish Samples (Pionite) RDM Industrial Products (Click Here)
See Custom Laminate Finish Samples (Wilsonart) RDM Industrial Products (Click Here)


RDM Industrial Products
Plastic-Laminated
ESD Static Control

ESD (Electrostatic Dissipative)
Plastic Laminate Surface Color Options:



(Pionite - Micastat)
NOT AVAILABLE   NOT AVAILABLE NOT AVAILABLE
ESD Grey
(SG248)
ESD Blue
(SB020)
ESD White
(SW837)
ESD Beige
(ST681)



(Nevamar - ARP Surface)
RDM Paint Finish - Light Grey

ESD White
(SW7028)
ESD Greystone (Light Grey)
(ST6055)
ESD Grey (Dark Grey)
(ST6025)

LIMITED AVAILABILITY
MIN. ORDER REQUIRED

ESD Beige
(SN2064)
ESD Black
(S6074)
ESD Almond
(SN2065)





Pionite
"ChemGuard™ "
RDM Industrial Products
Chemical-Resistant
Plastic Laminate

Chemical-Resistant Plastic Laminate
(PIONITE) Surface Color Options:

Pionite "ChemGuard™ "
(Plastic Laminate)

Specially-coated plastic laminate - Available in black suede finish (low-gloss)
or black crystal finish (medium-gloss).  1 1/4" thick.  Also see Specifications...



Nevamar
"ChemArmor™"
RDM Industrial Products
Chemical-Resistant
Plastic Laminate

Chemical-Resistant Plastic Laminate
(NEVAMAR) Surface Color Options:

Nevamar "ChemArmor™ "
(Plastic Laminate)

Colors with extraordinary chemical, wear and impact resistance,
as well as a Class 1 Fire Rating.  ChemArmor™ provides resistance to acids/bases, solvents, stains, indicators and general reagents. It all adds up to laminates that keep looking new longer in even the harshest environments. It's ideal for interior horizontal surfaces in laboratories, healthcare facilities, schools, photo processing, forensic labs and more.  Also see Specifications...



Trespa
"TopLab™ "
RDM Industrial Products
Chemical Resistant
Solid Surface

Chemical/Heat-Resistant
Solid Surface Options - TRESPA:

RDM Industrial ProductsRDM Industrial ProductsRDM Industrial Products
Trespa "TopLab"
(Solid Surface)
Note: Black is the Most Readily Available Color
RDM Industrial Products
Speckles Collection:
RDM Industrial Products RDM Industrial Products RDM Industrial Products
  Mystic White / Blue Limestone
Yellow / Saffron
Patel Gray / Silver

RDM Industrial Products
Uni Colours Collection:
RDM Industrial Products RDM Industrial Products RDM Industrial Products
White (Standard) Pastel grey (Std.) Silver Grey  (Std.)
RDM Industrial Products RDM Industrial Products
Limestone Yellow  Canyon red  Mystic White
RDM Industrial Products RDM Industrial Products RDM Industrial Products
  Glacier Blue (Std.) Polar Green  Black (Standard)
Additional Charge(s) may apply for smaller order quantities or non-Standard Colors.

TopLabPLUS is Superbly Resistant to Chemicals.

It is perfect for use as a work surface in laboratories where there are stringent requirements for
chemical resistance and decontamination in the chemical, physical, microbiological and clinical areas.

Chemically Resistant.
Heat resistant. It can be continuously exposed to temperature up to 284° and it can withstand short-term (20 min.) exposure of up to 356°.
Easy to clean.
TopLabPLUS has minimal joints, reducing the risk of contamination and simplifying cleaning.
Machinable.
It can be worked liked hardwood, and it is easy to incorporate drip grooves, sinks, cupsinks and fixtures into the lab design.
Hygienic. The smooth, non-porous surface of
TopLabPLUS does not support the growth of bacteria or fungi, and micro-organisms cannot penetrate its core.
Stain resistant.
TopLabPLUS is extremely resistant to most histological and microscopical dyes and stains.
Easy to decontaminate.
TopLabPLUS panels are suitable for radio-labelled compounds and are easy to decontaminate.
Moisture resistant.
TopLabPLUS is highly resistant to humidity and suitable for such wet environments as botanical research labs and sink area installations.



Epoxy Resin
RDM Industrial Products
Chemical Resistant
Solid Surface - Epoxy

Chemical/Heat-Resistant
Solid Surface Options - Epoxy Resin:



Note: Black is the Most Readily Available Color
Epoxy Resin - Black Epoxy Resin - New Alpine White Epoxy Resin - Graphite Epoxy Resin - Gray
Black New Alpine White Graphite Gray
Epoxy Resin - Forest Green Epoxy Resin - Steel Blue Epoxy Resin - Tan
Forest Green Steel Blue Tan
Additional Charge(s) may apply for smaller order quantities.






Other Top Options

Other Top Options:
Hard Board Masonite Top
Hard Board
Masonite
(Economical & Durable)
Laminated Hardwood Top
Laminated
Hardwood
(i.e. Butcher Block Maple)
Stainless Steel Top
Stainless
Steel
(Brushed & Polished)



Steel Top Options

Steel Top Options:
Perforated Steel Top Brushed Stainless Steel Top

Stainless Steel
Perforated Top
Stainless Steel
(#4 Brushed Finish)
Stainless Steel
(#2B Smooth Finish)

Steel Top with Raised Perimeter Curb
Steel Plate Top
Shown with Optional
Raised Perimeter Curb




Plastic Top Options

Plastic Top Options:
    HDPE Top
Polypropylene Top   HDPE Plastic Top


Edge Options
for Tops

- Top Edge Options -
Laminated 180-Degree Rolled Front Edge Laminated Waterfall Edge Bull Nosed Laminated Edge
180-Degree
Rolled Edge
Waterfall
Edge
Bull-Nosed
Laminate Edge

Self Edge Laminated Top Stainless Steel Folded Edge T-Molded Edge
Self- Edge
Laminate
Stainless Steel
Folded Metal Edge w/
Welded Corners
PVC T-Moulding,
Black, White, Brown

3mm PVC Top Edging  Steel Top with Raised Perimeter Curb Laminated Perimeter Curb
PVC Edging Black,
White, Almond, Light Grey
and Dark Grey Colors
Steel Plate Top with
Raised Perimeter Curb
(Containment Curb)
Plastic Laminated Top w/
Laminated Raised Curb

RDM Industrial Products  RDM Industrial Products  Extruded Aluminum Top Edge
Stainless Steel
Bullnose Perimeter
w/ Welded Corners
(Containment Curb)
Steel Plate Top with
Textured Slip-Resistant
Rubberized Surface
Extruded Aluminum Edge
Great for Securing or
Attaching Accessories !!


Panolam
Industrial-Quality

Melamine
Surface Options
(Subject to Availability)

Melamine Surface Color Options:

Panolam Melamine Item:

Plastic Laminate Equivalent:
Part # Description Sample: Brand Description Part #
S 411 Oxford White Wilsonart Frosty White 1573-60
S 445 Almond Wilsonart Natural Almond D30-60
S 548 Custom Grey Wilsonart Fashion Grey D381-60
S 551 Fog Grey Formica Fog 961-58
S 405 Black Wilsonart Black 1595-60


Powder Coating
Color Options
(Laboratory Cabinets
& Casework Only)


Powder Coating Color Options:
(For Metal Laboratory Furniture - Casework / Fume Hoods / Cabinets)
SB-MAX-A Laboratory Fume Hood - Airfoil Add Air Fume Hood       Standard Steel Laboratory Casework
Light Almond Ivory Beige Off White  Platinum  Matte Grey
Light Almond Ivory Beige Off White Platinum Matte Grey
  Black     White
  Black     White
Dark Taupe  Green  Light Blue  Sea Blue  Deep Blue  Burgundy
Dark Taupe Green Light Blue Sea Blue Deep Blue Burgundy

Note:  These are appx. color representations and may vary slightly from actual finish.
All Drawer Bodies and Shelves (Interior Pieces) are E6328 Off White.



Please minimize or close this window to return to the
previous page and input your finish selections...
